Repair
Exhaust gas aftertreatment system (depending on configuration)
Specific safety instructions
DANGER
Crushing, shearing or impact hazards by instable transportation conditions or losing control of
the means of transport, load or loose part.
Loss of control of the load, of any loose part or means of transport will result in death or
serious injury.
u Secure the means of transport.
u Use only adapted means of transport.
u Fix or remove any loose part on the load.
u Pay attention to the center of gravity and the total weight.
u Ensure the load against slipping and toppling.
Special tools
Not applicable.
Consumables and equipment
Not applicable.
Overview
Fig. 275: Task overview
1
Diesel exhaust fluid pump 5 Connection (M26)
2 Screw (M10) 6 10-pin connector
3 Lifting hook 7 48-pin connector
4 Connection (M22)
KD62V12 33525088601_8_1 EN_US
2022-09
© 2022 by Kohler Co. All rights reserved.
253
