Kohler KD62V12 User Manual

Appendix
Standard tightening torques
Thread Y Form A with sealing edge Form B with sealing ring Form E with flat sealing
G 1/8A 7 Nm
5 ft-lb
14 Nm
10 ft-lb
14 Nm
10 ft-lb
G 1/4A 28 Nm
21 ft-lb
28 Nm
21 ft-lb
28 Nm
21 ft-lb
G 1/4A 28 Nm
21 ft-lb
28 Nm
21 ft-lb
28 Nm
21 ft-lb
G 3/8A 36 Nm
27 ft-lb
56 Nm
41 ft-lb
56 Nm
41 ft-lb
G 1/2A 52 Nm
38 ft-lb
112 Nm
83 ft-lb
72 Nm
53 ft-lb
G 1/2A 52 Nm
38 ft-lb
80 Nm
59 ft-lb
72 Nm
53 ft-lb
G 3/4A 72 Nm
53 ft-lb
144 Nm
106 ft-lb
144 Nm
106 ft-lb
G 1A 120 Nm
89 ft-lb
264 Nm
195 ft-lb
248 Nm
183 ft-lb
G 1 1/4A 192 Nm
142 ft-lb
432 Nm
319 ft-lb
360 Nm
266 ft-lb
G 1 1/2A 232 Nm
171 ft-lb
504 Nm
372 ft-lb
432 Nm
319 ft-lb
Tab. 67: Standard torques for imperial thread unions L series, for aluminium – see figure above
Standard torques for imperial thread unions S series (up to 800
bar/11603 Psi) for aluminium
According to ISO1179-1 / DIN 3852-T2-Form X / DIN 3852-T3-Form X BSP threading.
Information
Tolerances of the indicated tightening torques: 10%.
Always lubricate the thread before tightening these parts (engine oil).
Thread Y Form A with sealing edge Form B with sealing ring Form E with flat sealing
G 1/8A 29 Nm
21 ft-lb
45 Nm
33 ft-lb
45 Nm
33 ft-lb
G 1/4A 28 Nm
21 ft-lb
44 Nm
32 ft-lb
32 Nm
24 ft-lb
G 1/4A 28 Nm
21 ft-lb
44 Nm
32 ft-lb
32 Nm
24 ft-lb
G 3/8A 36 Nm
27 ft-lb
72 Nm
53 ft-lb
64 Nm
47 ft-lb
G 1/2A 52 Nm
38 ft-lb
120 Nm
89 ft-lb
92 Nm
68 ft-lb
G 1/2A 52 Nm
38 ft-lb
104 Nm
77 ft-lb
92 Nm
68 ft-lb
KD62V12 33525088601_8_1 EN_US
2022-09
© 2022 by Kohler Co. All rights reserved.
279
