Repair
Covers
Fig. 45: Removing co
ver - back part
u
Remove nuts
6
, vibr
ation dampers
3
, distance sleeves
2
and pins
1, 4
.
u
Remove cov
er - back side
5
Installation
Fig. 46: Installing pins
u
Screw pins
1, 4
on aggr
egate support and PTO br
acket.
62
© 2022 by Kohler Co. All righ
ts reserved.
KD62V12 33525088601_8_1 EN_US
2022-09
61
63
