Repair
Rocker arms
Special tools
Special tool Designation
Turning device
Tab. 11: Special tools
Consumables and equipment
Not applicable.
Overview
Fig. 53: Cylinder designation - direction of rotation according to ISO 1204
A1-A6
Series of cylinders – Bank A - Exhaust valves
B1-B6 Series of cylinders – Bank B + Inlet valves
DE Driving End (engine rear) L Left engine side
FE Free End (engine front) R Right engine side
DoR Direction of rotation
KD62V12 33525088601_8_1 EN_US
2022-09
© 2022 by Kohler Co. All rights reserved.
69
