Kohler KD62V12 User Manual

Repair
Rocker arms
Step 8
u Stop at flywheel groove index 2.
u Set valve clearance for cylinders A1, A2 and B2. (For more information see: Checking valve
clearance, page 73.) , (For more information see: Setting valve clearance, page 73.)
Step 9
u Pass flywheel groove index 6.
Step 10
u Pass flywheel groove index 3.
Step 11
u Stop at flywheel groove index 4.
u Set valve clearance for cylinders A4, B4 and B6. (For more information see: Checking valve
clearance, page 73.) , (For more information see: Setting valve clearance, page 73.)
Valve set order (alternative method)
Information
There is a marking on the flywheel to set the valve clearance.
The marking may become illegible.
The only possibility is to set by overlap position.
Ignition TDC* A1 B2 A2 B4 A4 B6 A6 B5 A5 B3 A3 B1
Overlap TDC** A6 B5 A5 B3 A3 B1 A1 B2 A2 B4 A4 B6
* Ignition order
** Opposite cylinder (overlap)
Tab. 13: Valve set order
u Set cylinder to overlap TDC position.
u Adjust valve clearance of ignition TDC cylinder.
72
© 2022 by Kohler Co. All rights reserved.
KD62V12 33525088601_8_1 EN_US
2022-09
