Repair Service and Repair Manual
Exhaust gas system
Specific safety instructions
WARNING
Risk of injuries by contact with hot surfaces!
Engine is hot near operating temperature.
u Avoid any contact with the engine, parts carrying hot coolant or oil, the exhaust system, the
turbocharger, the heat protection, the battery and the covers.
u After the temperature has cooled down to a level it can be touched, proceed with the tasks on
the engine.
Special tools
Not applicable.
Consumables and equipment
– Hot temperature grease
– Rags
Overview
Fig. 210: Task overview
1 Compensator 3 V-clamp
2 Seal
Removal
u Loosen V-clamps 3.
u Remove compensators 1 with seals 2.
186
© 2021 by Kohler Co. All rights reserved.
KD83V16 33525088901_2_1 EN_US
2021-07
