GENERAL INFORMATION
1
13
EN
Some components are for illustrative purposes only and may vary.
NOTE: Components in Pos. 4, 5, 6 are not supplied by Kohler.
POS.
DESCRIPTION
1
SCR system control unit
2
AdBlue tank
3
AdBlue pump
4
AdBlue intake tube
5
AdBlue delivery tube to AdBlue injector
6
Return tube in AdBlue tank
7
AdBlue injector
