6
INFORMATION ABOUT REPLACEMENTS
EN 50
6.4 Air filter cartridge replacement
•
Before proceeding with operation, read Par. 3.2.2
NOTE: Component not necessarily supplied by KOHLER.
1.
Pull insert F to unlock cover A.
2.
Rotate counter clockwise and remove cover A.
6.9
3.
Remove the cartridges B and G.
4.
Fit cartridges G and B.
5.
Fit cover A by performing the operations indicated in
points 2 and 1 in the reverse order.
6.10
