Kohler KDI 3404TCR-SCR User Manual

2
TECHNICAL INFORMATION
EN 24
Chrome
mg/kg
< 0,2
Nickel
mg/kg
< 0,2
Aluminium
mg/kg
< 0,5
Magnesium
mg/kg
< 0,5
Sodium
mg/kg
< 0,5
Potassium
mg/kg
< 0,5
Freezing point
°C
11
2.7 Coolant recommendation
A mixture of 50% demineralized water and 50% low silicate ethylene glycol based coolant liquid must be
used. Use a Long Life or Extended Life Heavy Duty OAT coolant free of: silicates, phosphates, borates,
nitrites and amines.
The following ethylene-glycol based engine coolant for all models within KDI engine family may be used:
•
OAT (Organic Acid Technology) Low Silicate: ASTM D-3306 D-6210
•
HOAT (Hybrid Organic Acid Technology) Low Silicate: ASTM D-3306 D-6210
The above coolants in concentrated formulation must be mixed with distilled, deionized, or demineralized
water. A pre-mixed formulation (40-60% or 50-50%) can be used directly when available.
Important
•
Do not mix ethylene glycol and propylene glycol based coolants. Do not mix OAT and
HOAT based coolant. OAT performance life can be drastically reduced if contaminated with
nitrite-containing coolants.
•
Never use automotive-type coolants. These coolants do not contain the correct additives to
protect heavy – duty diesel engines.
OAT coolants are maintenance free up to 6 years or 6000hrs of operation , provided that the cooling
system is topped up using the same type of coolant. Do not mix different coolant types. Test the coolant
condition annually with coolant test strips.
HOAT are not all maintenance free and it is recommended to have SCA (Supplemental Coolant Additives)
added at the first maintenance interval.
2.8 Battery recommendation
Battery not supplied by Kohler
2.6
RECOMMENDED BATTERIES
AMBIENT TEMPERATURE
BATTERY TYPE
≥ - 15°C
120 Ah/20 h - 1000 CCA/SAE
< -15°C
130 Ah/20 h - 1100 CCA/SAE
