5
INFORMATION ABOUT MAINTENANCE
EN 42
5.8 Check Poly-V alternator belt
•
Before proceeding with operation, read Par.
3.2.2 .
Warning
•
For safety precautions see Cap. 3
.
NOTE: The poly-v belt is not adjustable.
Check the belt A condition, if worn out or deteriorated, replace
it.
NOTE: Make sure that the ribs of the belt A are inserted
correctly into the grooves of the pulleys B (as shown in D1
and D2).
Start the engine and run it for some minutes, then turn off it,
and let it cool down at ambient temperature. Check by the
appropriate tool that at point p the tension value is between
135 and 178 Hz.
NOTE: If the poly-v belt tension results out of the above
mentioned values contact KOHLER authorised workshops
for replacement.
NOTE: Belts A2, A3 are not supplied by KOHLER. Refer to
the technical documentation of the vehicle..
5.5
5.6
5.9 Filter cartridge and fuel pre-filter check
•
Before proceeding with operation, read Par.
3.2.2 .
Warning
•
For safety precautions see Cap. 3
.
When turn on lights on control water filter cartridge fuel:
1.
Gently loosen the wing screw A without removing it.
2.
Drain the water if present.
3.
Re-tighten the wing screw A as soon as the fuel begins
to flow.
5.7
