Kohler KDI 3404TCR-SCR User Manual

GENERAL INFORMATION
1
15
EN
Some components are for illustrative purposes only and may vary.
NOTE: Components in Pos. 1, 2, 4, 5, 6 are not supplied by Kohler.
POS.
DESCRIPTION
1
Air filter
2
Air intake sleeve
3
Turbocharger
4
Air delivery tube to Intercooler
5
Intercooler
6
Air delivery tube to intake manifold
7
Air inlet valve
8
Exhaust gas delivery hose to SCR
9
AdBlue injector
10
SCR

Kohler KDI 3404TCR-SCR Specifications

General

Brand	Kohler
Model	KDI 3404TCR-SCR
Category	Engine
Language	English
