6
Installing Cabinet into Window
Follow the steps listed below to install the cabinet into the window.
1. Center empty cabinet into window:
• Check that lower rail of air conditioner cabinet is behind and against back side of window
sill.
• Maintain a firm hold on the cabinet and lower window sash to hold the cabinet in place.
• Measure the distance of the right side and left and adjust until equal distance.
2. There are different methods to secure the cabinet into window depending on the type of
window.
• For Wooden Frames:
- Use a 3/16” drill bit to drill three starter holes 3/8” deep through the three holes in the
cabinet and into the window sill.
- Drill one starter hole 3/8” deep through the hole in the middle of the top rail and into the
window frame.
• For Vinyl Windows:
- Use a 1/8” drill bit to drill one hole through the hole in the middle of the top rail into the
window frame. Attach the cabinet to the window with one #10 x ¾” Phillips screw (B in
figure above).
- Place two safety locks into the holes that are located at the bottom of the cabinet and
drive two locking screws through the safety locks into the cabinet as shown below:
