3
Preparations for Installation
Note: To avoid risk of injury and/or product/property damage, please take the following precautions:
- Two or more people are needed to properly handle and install.
- Use proper lifting and carrying techniques.
- Before installation, make sure to inspect the window and sill to ensure they are able to handle the
weight and size of this unit.
- Wearing protective gloves will help to avoid injury from sharp edges.
Before you begin, make sure you have all the parts necessary for installation.
If you have multiple windows, choose one that is near an electrical outlet that will be able to
provide sufficient power to your unit. See the power requirements listed on the product label
printed on the side or the back of your window air conditioner.
The following measurements are required to properly install the air conditioner.
• Window Width: 26 7/8” to 36”
Parts Supplied:
(3) #10 x ½” Phillip Screws (1) Top Channel
(7) #10 x ½” Flat Screws (1) Window Sash Seal
(5) #10 x ¼” Phillip Screws (1) Foam Seal
(1) Set of Side Curtains (1) Window Lock Bracket
(2) Safety Lock (only vinyl windows) (5) Weather Seals
