I.4.2 The digital servo amplifiers of the SERVOSTAR™ 600 family
Standard version
l
5 current ratings (1.5A,3A,6A,10A,14A,20A)
l
two instrument widths : 70 mm up to 10A rated current
100 mm for 14 up to 20A rated current
l
wide range of rated voltage (3x230V –10% to 3x480V +10%)
l
shield connection directly at the servo amplifier
l
two analog setpoint inputs
l
integrated CANopen (default 500 kBaud), for integration into CANbus systems and for
setting parameters for several amplifiers via the PC-interface of one amplifier
l
integrated RS232, electrically isolated
l
integrated pulse-direction interface
O
ptions
l
-AS- built-in safety relay (personnel-safety starting lock-out),
see Chapter I.11.1 and leaflet “Option -AS-”
l
PROFIBUS DP expansion card (from 1st. quarter 1999)
l SERCOS expansion card (from 1st. quarter 1999)
l I/O expansion card
Open architecture
l open hardware and software architecture
l slot for an expansion card
l integrated macro language, including compiler
l
prepared for all conceivable customer-specific extensions
I.4.3 Operation directly from supply
Electrical supply
l
Directly off earthed 3~ system, 230V
-10%
— 480V
+10%
, 50 — 60 Hz,
TN-system or TT-system with earthed neutral point
l
Fusing (e.g. fusible cutout) provided by the user
l
single-phase supply (e.g. for commissioning or setting-up) is possible
Auxiliary supply voltage 24V DC
l
Electrically isolated, from an external 24V DC psu, e.g. with insulating transformer
Power input filter
l
Interference suppression filter for the supply input (to Class A) is integrated
l
Interference suppression filter for the 24V aux. supply (to Class A) is integrated
SERVOSTAR™ 600 Installation-manual 11
