Kollmorgen Seidel SERVOSTAR 600 Series Assembly, Installation And Commissioning Instructions

III.4.2 Encoder (X1)
As an option, the 6SM series of motors can be fitted with a single-turn or multiturn
sine-cosine encoder.
This encoder is used by the SERVOSTAR™ 600 as a feedback device for drive tasks which
require highly precise positioning or extremely smooth running.
If lead lengths of more than 100m are planned, please consult our applications department.
The thermostat contact in the motor is connected via the resolver cable to the
SERVOSTAR™ 600 and evaluated there.
- A.4.031.1/27
40 SERVOSTAR™ 600 Installation-manual
Interfaces 02.99 - A.4.031.1/27 Kollmorgen
