Err_d: LOAD SENSOR ERROR (≥ P2.03) - The load sensor signal is out of normal range
(3,9-6,1 VDC).
Normal action:
1 Check the wiring and fitting of the load sensor.
2 Measure the voltage between CU1:2 and CU1:4 (ca. 9,85 VDC).
-If the voltage is ca. 9,85 VDC, continue at step 4.
3 Switch the power off. Disconnect the load sensor wire from CU1:4. Switch the
power on and measure the voltage between CU1:2 and CU1:4 (ca. 9,85 VDC).
-If the voltage is ca. 9,85 VDC, change or fix the load sensor.
-If the voltage is not ca. 9,85 VDC, check that current in the load sensor
circuit is less than 100 mA, and if necessary, change the load sensor or the
CU1.
-Reconnect the load sensor wire to CU1:4.
4 Measure the load signal voltage between CU1:2 and CU1:3 (3,9 - 6,1 VDC).
-If the load signal voltage is within the range, 3,9 - 6,1 VDC, change the
CU1.
5 Switch the power off. Disconnect the load sensor wire from CU1:3. Switch the
power on.
-If the load signal voltage measured from the wire is still out of the range,
change or fix the load sensor.
-Reconnect the load sensor wire to CU1:3.
6 Carry out the normal startup routine to ensure that the load sensor and the CU1
work correctly.
Err_E: HOIST REQUEST ERROR (≥ P2.10) - The CU1 has detected that the lifting request
was not ON for sufficient time to test its internal circuit (time required is about 0,15 sec).
Normal action: Normally does not require any actions. If the lifting request has
been ON for more than 0,15 seconds constantly and Err_E occurs repeatedly,
change the CU1.
Err_F: HIOK INPUT FAILURE (≥ P2.11) - The HIOK signal is ON when it should be OFF
(hoisting contactor A-K1 is energized). (The HIOK circuit checks that the CU1's switch
between CU1:9 and CU1:10 operates correctly).
Normal action: Replace the CU1.
