26.03.1996 • KHH SEENXL13A
•For Authorized KCI Service Agents Only•
KCI Hoists Corporation reserves the right to alter or amend the above information without notice
Page 47
XL
Service Manual
CU1
KCI KONECRANES GROUP
KCI HOISTS CORPORATION
APPENDIX 11: CU1 technical data
Rated control voltage range: 42 VAC - 230 VAC (-10% to +15%)
Supply voltages: 11 VAC and 18 VAC
-low voltage detector in 11VAC circuit operates if
U11VAC is
a) -15% for 25 msec time (≥ P2.12)
b) -10% with no delay (< P2.12)
Frequency: 50/60 Hz
Operating ambient temperature: -20°C to +55°C
Storage temperature: -30°C to +90°C
Humidity: 90%RH (no condensation)
Mechanical dimensions (mm): 70 x 75 x 100 (Width x Height x Depth)
