APPENDIX 10:
APPENDIX 10:APPENDIX 10:
APPENDIX 10: CU1 program versions
CU1 program versionsCU1 program versions
CU1 program versions
This appendix lists the main modifications of the CU1's program.
Version P2.00
Version P2.00Version P2.00
Version P2.00
- The form of the passwords have been changed (e.g. 1-xxx)
- the Err_A message has been added
- The load is displayed within range -20...120 %
- The internal diagnostic values can be read with the password 1-113
- The HIOK circuit is not tested if it is less than 5 seconds since the previous lift.
- The 'hoisting motor running (active)'-data is waited for 150 msec
- A 'PASS'-message is displayed after the password 3-000.
- It is possible to enter into the programming mode with the blue push-button
in standstill.
- It is possible to calibrate the load sensor with a 50...99% load instead of
100%.
Version P2.01
Version P2.01Version P2.01
Version P2.01
- The Err_b and Err_C messages have been added.
- The diagnostic values can be reset by the password 3-511/sup 9.
- The number of overloading incidents is updated after 5 seconds standstill.
- The cooling down and warning state times have been modified to be 2 and
3 minutes.
- If the load is less than -10% it blocks out lifting after 4 seconds time.
Version P2.02
Version P2.02Version P2.02
Version P2.02 (from serial no. N890150, December 1989)
- The Err_9 message has been added
Version P2.03
Version P2.03Version P2.03
Version P2.03 (from serial no. N890290, February 1990)
- CU1's circuit board has been modified, D19 and D20 removed
- The password 1-125 has been added
- The Err-d messages has been added
-In the setup mode full and no-loads are asked as 'SLxxx' and 'SL 0'
- The weight of the load is displayed as 'L XXX' in the load mode
Version P2.10
Version P2.10Version P2.10
Version P2.10 (from serial no. A900127, September 1990)
- The Err_4 and Err_E messages have been added
- Diagnostic values have been added (8-, 9-, A-, b-)
Version P2.11
Version P2.11Version P2.11
Version P2.11 (from serial no. A900919, May 1991)
- The Err_10- and Err_F messages have been added
Version P2.12
Version P2.12Version P2.12
Version P2.12 (from serial no. A921210, November 1992)
- The password 1-000, 1-001, 1-010, 1-011, 1-100, 1-101, 2-224, 2-601, 2-645
and 2-865 have been added
- SUP6 added to password 3-511
- The functional options 1, 2 and 3 have been added
- Err_3, low voltage detector is activated if 11VAC voltage is -15% for 25 msec
time (before the program version P2.12 it was -10%, no delay)
- If password 1-125 is used, the overheating and brake wear control circuits
remain valid
- FEM-group 5m has been added (CL 6) as well as code CL0 that keeps the
earlier selected FEM-class valid
