Instruction manual
20220513E 21
2.7 NFU Steering Lever
The rudder will move as long as the lever is offset to Port or
Starboard.
2.8 Hand held remote
STBY-AUTO
REMOTE
R3000X
STBY/AUTO mode button.
AUTO mode is when lamp is lit
Push buttons for Port and
Stbd NFU commands
Note ! When in AUTO mode, pressing the buttons will change
the set course 1° each press. If you keep the button
pressed, it will automatically change the course at a rate
of 3
°
/second. Refer to page 35 for further information.
2.9 Standby-Nav mode
When a Navigation receiver is connected to the AP11 you
can steer the boat manually using the STBY-NAV mode
display(s) as shown, or you can steer the boat automatically
using the Nav. receiver signals to adjust the boats course to
steer (see page 28).
