8
Standard Accessories
Lens Cap CS-A31
Attached to objective lens for protecting it
when not using this instrument.
USB Cable (2 m) CS-A32
Used for communication between this
instrument and PC.
AC Adapter AC-A312
Supplies power from AC outlet.
Input: 100 - 120 V or 200 - 240 V
0.75 - 0.42 A
50/60 Hz
Output: 12 V
3 A
Data Management Software
CS-S10w Professional
Software to control this instrument from PC
for various data management.
The protect key is attached.
Screw for focus ring lock CS-A38
Locks the focus adjustment ring of the CS-
2000/CS-2000A so that it does not move
unintentionally and change the focus.
· Do not use any screw except for the
attached screw. Should it be lost or
damaged, purchase a new CS-A38.
· When storing the CS-2000/CS-2000A in the Storage Case (optional accessory),
remove the screw.
· When storing the CS-2000/CS-2000A in the packing box for transfer, remove the
screw.
