MSH8900
www.symkloud.com // 74
Sensor name
Event/reading
type code
Sensor type
Sensor specific
offset
Event trigger
ShMC Redun State
7Eh
OEM ShMC
Redundancy
State
D4h
OEM ShMC
Redundancy
State
00h Out Of
Service
01h Acitve
02h Going
Stand-By
03h Stand-By
04h
Activating
05h
Shutdown
Event Data2:
bit[3:0]: previous state
bit[7:4]: Geographical
Address
00h = ShMC Slot 0
01h = ShMC Slot 1
Event Data3:
bit[7:0]: Cause of
transition
FPGA RW Status
FPGA Heartbeat
Remote Sh Health
7Fh
OEM Health
Severity
Status Sensor
24h
(Platform
Alert)
00h Status
not available
in current
state
01h Healthy
02h
Informational
fault
03h Minor
fault
04h Major
fault
05h Critical
fault
Event Data2:
If the sensor is an aggregation
sensor, then event data 2 is
used to return the ID of the
first sensor from the
aggregation that caused the
fault.
Event Data3:
Not used
Chassis Health
7Fh
OEM Health
Severity
Status Sensor
24h
(Platform
Alert)
00h Status
not available
in current
state
01h Healthy
02h
Informational
fault
03h Minor
fault
04h Major
fault
05h Critical
fault
Event Data2:
If the sensor is an aggregation
sensor, then event data 2 is
used to return the ID of the
first sensor from the
aggregation that caused the
fault.
Event Data3:
Not used
