Sensor name
Event/reading
type code
Sensor type
Sensor specific
offset
Event trigger
Health Status
7Fh
OEM Health
Severity
Status Sensor
24h
(Platform
Alert)
00h Status
not available
in current
state
01h Healthy
02h
Informational
fault
03h Minor
fault
04h Major
fault
05h Critical
fault
Event Data2:
If the sensor is an aggregation
sensor, then event data 2 is
used to return the ID of the
first sensor from the
aggregation that caused the
fault.
Event Data3:
Not used
Sensor Aggregation List:
ID - Sensor Name
11 - Temp On-Board
12 - Temp Eth Switch
13 - Temp Quad Phy
14 - Temp Inlet
15 - Temp Phy 10G
16 - Vcc +12V In
17 - Vcc +5V SUS
18 - Vcc +3.3V SUS
19 - Vcc +1.8V SUS
20 - Vcc +1.5V SUS
21 - Vcc +1.25V SUS
22 - Vcc +1.2V SUS
23 - Vcc +0.75V SUS
24 - Vcc +3.3V
25 - Vcc +2.5V
26 - Vcc +1.8V
27 - Vcc +1.2V
28 - Vcc +1.0V
29 - Vbat +3V
53 - Fan Fault
63 - Power Good Latch
64 - FPGA RW Status
65 - FPGA Heartbeat
72 - ShMC Redun State
