Parameters of each mode
26
TABLE....................................................................[OFF, ON]
Switches the parameter display.
OFF: Close-up display of the parameters of the selected tim-
bre.
ON: Display the parameters for all eight timbres.
LINK .....................................................................[OFF, ON]
Links adjustments for the programs of several timbres.
Click the [LINK] switch for each timbre you want to link.
You can also turn linking on or off for all timbres by using
the [ALL LINK ON] and [ALL LINK OFF] switches located
below the [TABLE] switch.
ON (ALL LINK ON) ................................................[OFF, ON]
If you click this to select “ALL LINK ON,” the “LINK” set-
ting of all timbres will be on. Click this again to return to the
state prior to when you selected “ALL LINK ON.”
OFF (ALL LINK OFF) ...............................................[OFF, ON]
If you click this to select “ALL LINK OFF,” the “LINK” set-
ting of all timbres will be off. Click this again to return to the
state prior to when you selected “ALL LINK OFF.”
OSC
BALANCE..................................................[–50…+00…+50]
Adjusts the volume of the oscillators.
If the program’s “OSC MODE” is Double, this adjusts the
volume balance of OSC1 and OSC2. The adjusted value is
added to the OSC1 “OSC LEVEL,” and subtracted from the
OSC2 “OSC LEVEL.”
VDF
RESONANCE.............................................[–50…+00…+50]
Adjusts the VDF resonance. The adjusted value is added to
the VDF1 and VDF2 “RESONANCE.”
This setting is unavailable if the OSC page “RESO-
NANCE Switch” (p.35) is OFF.
CUTOFF ....................................................[–50…+00…+50]
Adjusts the VDF cutoff frequency. The adjusted value is
added to the VDF1 and VDF2 “CUTOFF.”
EG INT......................................................[–50…+00…+50]
Adjusts the VDF “EG INT.” The adjusted value is added to
the VDF1 and VDF2 “EG INT.”
