Combination mode
39
Drum Parameters
This screen will appear if “OSC MODE” is set to DRUMS.
DRUMS
DRUM KIT SELECT............................................... [BROWSER]
Here you can select a drum kit.
OSC LEVEL............................................................. [00…99]
Specifies the oscillator’s output level.
OCTAVE ..............................................................[4’, 8’, 16’]
Selects the octave of the oscillator.
PITCH EG
Specify the shape of the pitch EG. Drag the points of the
graphic envelope to specify the shape of the EG. (☞ “Graph-
ical envelopes” on page 9)
☞ M1 owner’s manual PDF, page 24 “F1-1: OSC1 PITCH EG”
VEL SENS
EG INT......................................................[–99…+00…+99]
Specify how velocity will affect the depth of the EG.
EG TIME.................................................... [–99…+00…+99]
Specify how velocity will affect the speed of the EG.
DRUM KIT EDIT
INDEX KEY........................................... [000: C-1…127: G9]
Here you can select the note that you want to edit.
DRUM SOUND................................................... [BROWSER]
Here you can select a drum sound.Click the [BROWSER]
switch to access the browser (☞ “The Browser” on page 16),
and make your selection by dragging up/down or by click-
ing (Key Focus) and using your computer’s up/down/left/
right cursor keys.
