Korg Pandora Stomp - Synth Parameters

31
Synth parameters
TheSynthiseffectiveonlywhensinglenotesareplayed.Thedesiredeffectwill
notbeobtainedifchordsareplayed.
Ifyourinstrumentisnottunedcorrectly,theresultsmaynotbeasyouexpect.In
thiscase,re‐tuneyourinstrument.
THRESHOLD
Adjusts the sensitivity of the synth in response to the volume of the
guitar or bass. (1.0–10.0)
OSC TYPE
0: Sawtooth wave, two octaves down. 1: Sawtooth wave, one octave down.
2: Sine wave, one octave down. 3: Sawtooth wave.
4: Sine wave. 5: Sawtooth wave, one octave up.
6: Sine wave, one octave up. 7: Sine wave, two octaves up.
Oscillators 8–15 are oscillators 0–7 but with portamento turned on.
VCF
Voltage Controlled Filter sensitivity adjustment.
0.0–4.7 is sensitivity adjustment in the positive (+) direction, and 5.0–10.0 is
sensitivity adjustment in the negative (-) direction.
Set this to 5.0 for a sine wave oscillator.
SYN LVL Adjusts the volume of the synth. (0.0–10.0)
