Technical Specifications
DSP-62-AEC Technical Specifications
Inputs
2 HDMI
On female HDMI connectors
1 Unbalanced Stereo Audio
On a 3.5mm mini jack
4 Balanced Mono Audio
On 3-pin terminal block connectors
Outputs
1 HDMI
On a female HDMI connector
1 Balanced Stereo Audio
On a 5-pin terminal block connector
Ports
1 USB Audio
On a USB B connector
1 RS-232
On a 3-pin terminal block
1 Ethernet
On an RJ-45 female connector
Video
Max Bandwidth
18Gbps (6Gbps per graphic channel)
Max Resolution
4K@60Hz (4:4:4)
Compliance
HDMI and HDCP 2.2
Line/Mic Level
Input
Impedance Unbalanced
Impedance Balanced
Impedance Microphone
7.6kΩ
3.8kΩ
3.8kΩ
Nominal level Unbalanced
Nominal level Balanced
0dBV (0.77Vrms)
+6.8dBu (1.54Vrms)
Maximum level (Balanced)
+8dBu (2Vrms)
Sensitivity Unbalanced
Sensitivity Balanced
Full power @ 0dBV (0.77Vrms)
Full power @ +6dBu (1.54Vrms)
Phantom Power
48 VDC on/off per input
Line Level
Output
Impedance Unbalanced
Impedance Balanced
500Ω
Frequency Response
20Hz - 20kHz @ +/-1dB
S/N Ratio:
>85dB, 20Hz - 20kHz, at unity gain (unweighted)
Audio THD + Noise:
<0.01%, 20 Hz - 20kHz, at unity gain
Crosstalk
<-85dB, 20Hz to 20kHz
Controls
Front Panel
DIP-switches, 6 input and 2 output audio status
LEDs, 1 power on LED
Control RS-232
Baud Rate
115200
Supported
Web Browsers
Windows
Chrome
Power
Consumption
630mA
Source
PoE or 12V DC, 5A
Environmental
Conditions
Operating Temperature
0° to +40°C (32° to 104°F)
Storage Temperature
-40° to +70°C (-40° to 158°F)
Humidity
10% to 90%, RHL non-condensing
Regulatory
Compliance
Safety
CE, FCC
Environmental
RoHs, WEEE
Enclosure
Size
DemiTOOLS®
Type
Aluminum
Cooling
Convection Ventilation
General
Net Dimensions (W, D, H)
19.1cm x 6cm x 2.7cm (7.5" x 2.4" x 1.1")
Shipping Dimensions (W, D, H)
34.5cm x 16.5cm x 5.2cm (13.6" x 6.5" x 2.1")
Net Weight
0.16kg (0.4lbs)
Shipping Weight
0.6kg (1.3lbs) approx.
Accessories
Included
Power adapter cord
Specifications are subject to change without notice at www.kramerav.com
