DSP-62-AEC, DSP-62-UC – Protocol 3000
60
Function
Description
Syntax
Parameters/Attributes
Example
DISPLAY?
Get output HPD status.
COMMAND
#DISPLAY?out_id <CR>
FEEDBACK
~nn@DISPLAYout_id,status<CR><LF>
out_id – Output number
1 – HDMI output
status – HPD status according to
signal validation
0 – Signal or sink is not valid
1 – Signal or sink is valid
Get the output HPD status of
Output 1:
#DISPLAY?1<CR>
DSP-AEC
Set DSP field value.
COMMAND
#DSP-AECfield_id,signal_id,value<CR>
FEEDBACK
~nn@DSP-AECfield_id,signal_id,value<CR><LF>
Field_id
o bypass
<direction_type> – IN
▪<port_type> –
o ANALOG_AUDIO
▪<port_index> – The port number
as printed on the front or rear
panel
2 to 3
▪<signal_type> –
o AUDIO
▪<index> –
1
value –
For low-freq and high-freq
+20Hz to +20kHz (default-150)
For bypass
0– Off
1 – On
Set bypass on input 3 to off:
#DSP-AECbypass,IN.ANAL
OG_AUDIO.3.AUDIO.1,0<CR
>
DSP-AEC?
Get DSP field value.
COMMAND
#DSP-AEC?field_id,signal_id,valueCR>
FEEDBACK
~nn@DSP-AECfield_id,signal_id,value<CR><LF>
Field_id
o bypass
<direction_type> – IN
▪<port_type> –
o ANALOG_AUDIO
▪<port_index> – The port number
as printed on the front or rear
panel
2 to 3
▪<signal_type> –
o AUDIO
▪<index> – 1
value –
For low-freq and high-freq
+20Hz to +20kHz (default-150)
For bypass
0– Off
1 – On
get low frequency on input 3:
#DSP-AEC?low-
freq,IN.ANALOG_AUDIO.3.
AUDIO.1<CR>
DSP-COMP
Set DSP compressor
values.
COMMAND
#DSP-
COMPfield_id,<direction_type>.<port_type>.<port_index>.
<signal_type>.<index>,value<CR>
FEEDBACK
~nn@DSP-COMPfield_id,<direction_type>.<port_type>.<port
_index>.<signal_type>.<index1>,value<CR><LF>
Field_id
o Attack
o Release
o Threshold
o Ratio
o Gain
o Bypass
<direction_type> – IN
▪<port_type> –
o ANALOG_AUDIO
o ANALOG_STEREO
o USB_B
▪<port_index> – The port number as
printed on the front or rear panel
For ANALOG_AUDIO – 2 to 5
For USB_B, ANALOG_STEREO – 1
▪<signal_type> –
o AUDIO
▪<index> –
For ANALOG_AUDIO – 1
For USB_B, ANALOG_STEREO – 1, 2
value –
For attack time [ms]
0 to 100
For release time [ms]
0 to 10K
For threshold [dB]
-100 to 0
For ratio
[1 to 100]:1
For gain compensation [dB]
-100 to +15
For bypass [ms]
0– off
1 – on
Set attack time on input 3 to
15ms:
#DSP-COMPattack,IN.ANA
LOG_AUDIO.3.AUDIO.1,15<
CR>
