Kramer DSP-62-UC User Manual

Kramer Electronics Ltd.
DSP-62-AEC, DSP-62-UC – Protocol 3000
61
Function
Description
Syntax
Parameters/Attributes
Example
DSP-COMP?
Get DSP compressor
values.
COMMAND
#DSP-
COMP?field_id,<direction_type>.<port_type>.<port_index>
.<signal_type>.<index><CR>
FEEDBACK
~nn@DSP-COMPfield_id,<direction_type>.<port_type>.<port_
index>.<signal_type>.<index>,value<CR><LF>
Field_id
o Attack
o Release
o Threshold
o Ratio
o Gain
o Bypass
<direction_type> – IN
▪<port_type> –
o ANALOG_AUDIO
o ANALOG_STEREO
o USB_B
▪<port_index> – The port number as
printed on the front or rear panel
For ANALOG_AUDIO – 2 to 5
For USB_B, ANALOG_STEREO – 1
▪<signal_type> –
o AUDIO
▪<index> –
For ANALOG_AUDIO – 1
For USB_B, ANALOG_STEREO – 1, 2
value –
For attack time [ms]
0 to 100
For release time [ms]
0 to 10K
For threshold [dB]
-100 to 0
For ratio
[1 to 100]:1
For gain compensation [dB]
-100 to +15
For bypass [ms]
0– off
1 – on
Get attack time on input 3:
#DSP-COMP?attack
time,IN.ANALOG_AUDIO.3.
AUDIO.1<CR>
DSP-DELAY
Set DSP delay.
COMMAND
#DSP-
DELAYfield_id,<direction_type>.<port_type>.<port_index>
.<signal_type>.<index>,value<CR>
FEEDBACK
~nn@DSP-DELAYfield_id,<direction_type>.<port_type>.<port
_index>.<signal_type1>.<index>,value<CR><LF>
Field_id
o Delay
o Bypass
<direction_type> –
o IN
o OUT
▪<port_type> –
For IN
o HDMI_AUDIOo
For OUT
o USB_B
▪<port_index> – The port number
as printed on the front or rear
panel
1
▪<signal_type> –
o AUDIO
▪<index> – 1 to 2
value –
For delay time [ms]
0 to 150
For bypass [ms]
0– off
1 – on
Set delay time on USB channel
1 to 75:
#DSP-DELAYdelay,OUT.USB
_B.1.AUDIO.1,75<CR>
DSP-DELAY?
Get DSP delay.
COMMAND
#DSP-
DELAY?field_id,<direction_type>.<port_type>.<port_index
>.<signal_type>.<index><CR>
FEEDBACK
~nn@DSP-DELAYfield_id,<direction_type>.<port_type>.<por
t_index>.<signal_type>.<index>,value<CR><LF>
Field_id
o Delay
o Bypass
<direction_type> –
o IN
o OUT
▪<port_type> –
For IN
o HDMI_AUDIOo
For OUT
o USB_B
▪<port_index> – The port number
as printed on the front or rear
panel
1
▪<signal_type> –
o AUDIO
▪<index> – 1 to 2
value –
For delay time [ms]
0 to 150
For bypass [ms]
0– off
1 – on
Get bypass status on HDMI
input 1 to 75:
#DSP-DELAY?bypass,IN.HD
MI_AUDIO.1.AUDIO.1<CR>
