Kramer DSP-62-UC User Manual

Kramer Electronics Ltd.
DSP-62-AEC, DSP-62-UC – Protocol 3000
65
Function
Description
Syntax
Parameters/Attributes
Example
DSP-LIMITER?
Get DSP limiter.
COMMAND
#DSP-
LIMITER?field_id,<direction_type>.<port_type>.<port_inde
x>.<signal_type>.<index><CR>
FEEDBACK
~nn@DSP-LIMITERfield_id,<direction_type>.<port_type>.<po
rt_index>.<signal_type>.<index>,value<CR><LF>
Field_id
o Threshold
o Bypass
<direction_type> – OUT
▪<port_type> –
o ANALOG_STEREO
o USB_B
▪<port_index> – The port number
as printed on the front or rear
panel
1
▪<signal_type> –
o AUDIO
▪<index> – 1 to 2
value –
For threshold [dB]
-100 to 0
For bypass
0– Off
1 – On
Get bypass status on output:
#DSP-LIMITER?bypass,OUT
.ANALOG_STEREO.2.AUDIO.
1<CR>
DSP-METER?
Read DSP meters.
COMMAND
#DSP-
METER<direction_type>.<port_type>.<port_index>.<signal_
type>.<index>,type<CR>
FEEDBACK
~nn@DSP-METER<direction_type>.<port_type>.<port_index>.<
signal_type>.<index>,type,value<CR><LF>
<direction_type> –
o IN
o OUT
▪ <port_type> –
o HDMI
o HDMI_AUDIO
o ANALOG_AUDIO
o ANALOG_STEREO
o USB_B
o GENERATOR
▪<port_index> – The port number
as printed on the front or rear
panel
1 to 5
▪<signal_type> –
o AUDIO
▪<index> – 1
type –
1– Gain.
2 – Post-gain (for output only).
3– Expander (for input only).
4 – Compressor (for input only).
5 – Limiter (for output only).
value – [dBFS]
Read the limiter value on the
output:
#DSP-METERbypass,OUT.AN
ALOG_STEREO.1.AUDIO.1,5<
CR>
DSP-POST
Set DSP post volume
faders/mute.
COMMAND
#DSP-
POSTfield_id,<direction_type>.<port_type>.<port_index>.<
signal_type>.<index>,value<CR>
FEEDBACK
~nn@DSP-POSTfield_id,<direction_type>.<port_type>.<port_
index>.<signal_type>.<index>,value<CR><LF>
Field_id
o Level
o Mute
<direction_type> – IN
▪ <port_type> –
o ANALOG_AUDIO
o ANALOG_STEREO
o USB_B
▪<port_index> – The port number
as printed on the front or rear
panel
1 to 5
▪<signal_type> –
o AUDIO
▪<index> – 1
value –
For level [dB]
-100 to +15
For mute
0– Off
1 – On
Set mute status on input 2 to
ON:
#DSP-POSTmute,IN.ANALOG
_AUDIO.2.AUDIO.1,1<CR>
