DSP-62-AEC, DSP-62-UC – Protocol 3000
78
Function
Description
Syntax
Parameters/Attributes
Example
X-MIX-LVL?
Get DSP matrix cross-
point MIX level in dB.
This is an Extended
Protocol 3000
command.
COMMAND
#X-MIX-LVL?OUT.<port_type>.<port_index>.<signal_type>.<
index>,IN.<port_type>.<port_index>.<signal_type>.<index
><CR>
FEEDBACK
~nn@X-MIX-LVLOUT.<port_type>.<port_index>.<signal_type>
.<index>,IN.<port_type>.<port_index>.<signal_type>.<ind
ex>,dB<CR><LF>
The following attributes comprise the
primary signal ID (suffix 1) and follower
signal ID (suffix 2 or greater):
▪ <direction_type> – IN
o IN
o OUT
▪ <port_type> –
o HDMI
o HDMI_AUDIO
o ANALOG_AUDIO
o ANALOG_STEREO
o USB_B
o GENERATOR
▪ <port_index> – The port number
as printed on the front or rear
panel
▪ <signal_type> –
o AUDIO
▪ <index> – Indicates a specific
channel number when there are
multiple channels of the same type
▪ audio_level – [-100,24] dB with a
resolution of 0.1 dB.
Get analog audio output 1 and
HDMI audio cross-point level:
#X-MIX-LVL?
OUT.ANALOG_STEREO.1.AUD
IO.1,IN.HDMI_AUDIO.1.AU
DIO.1<CR>
X-MIX-MUTE
Set DSP matrix cross-
point mute state.
This is an Extended
Protocol 3000
command.
COMMAND
#X-MIX-MUTEOUT.<port_type>.<port_index>.<signal_type>.<
index>,IN.<port_type>.<port_index>.<signal_type>.<index
>,dB<CR>
FEEDBACK
~nn@X-MIX-MUTEOUT.<port_type>.<port_index>.<signal_type
>.<index>,IN.<port_type>.<port_index>.<signal_type>.<in
dex>,<mute_state><CR><LF>
The following attributes comprise the
primary signal ID (suffix 1) and follower
signal ID (suffix 2 or greater):
▪ <direction_type> – IN
o IN
o OUT
▪ <port_type> –
o HDMI
o HDMI_AUDIO
o ANALOG_AUDIO
o ANALOG_STEREO
o USB_B
o GENERATOR
▪ <port_index> – The port number
as printed on the front or rear
panel
▪ <signal_type> –
o AUDIO
▪ <index> – Indicates a specific
channel number when there are
multiple channels of the same type
▪ <mute_state> –
o 0
o 1
Mute analog audio output 1
and HDMI audio cross-point:
#X-MIX-MUTE
OUT.ANALOG_STEREO.1.AUD
IO.1,IN.HDMI_AUDIO.1.AU
DIO.1,0<CR>
X-MIX-MUTE?
Get DSP matrix cross-
point mute state.
This is an Extended
Protocol 3000
command.
COMMAND
#X-MIX-MUTE?OUT.<port_type>.<port_index>.<signal_type>.
<index>,IN.<port_type>.<port_index>.<signal_type>.<inde
x><CR>
FEEDBACK
~nn@X-MIX-MUTEOUT.<port_type>.<port_index>.<signal_type
>.<index>,IN.<port_type>.<port_index>.<signal_type>.<in
dex>,<mute_state><CR><LF>
The following attributes comprise the
primary signal ID (suffix 1) and follower
signal ID (suffix 2 or greater):
▪ <direction_type> – IN
o IN
o OUT
▪ <port_type> –
o HDMI
o HDMI_AUDIO
o ANALOG_AUDIO
o ANALOG_STEREO
o USB_B
o GENERATOR
▪ <port_index> – The port number
as printed on the front or rear
panel
▪ <signal_type> –
o AUDIO
▪ <index> – Indicates a specific
channel number when there are
multiple channels of the same type
▪ <mute_state> –
o 0
o 1
Get analog audio output 1 and
HDMI audio cross-point mute
state:
#X-MIX-MUTE?OUT.ANALOG
_STEREO.1.AUDIO.1,IN.HD
MI_AUDIO.1.AUDIO.1<CR>
