SwitchableUSB – 3 Supported Messages
8
3.2 Reply Device Information
This message is sent from a device to a client in response to a Request Device Information
message.
3.2.1 Field Descriptions
MAC Address
The device's MAC address.
IP Address
The device's current IP address.
Network Acquisition Mode
0=DHCP, 1=Static
Supported Protocol Version
All devices must support protocol 0 and one other protocol number. This
value specifies which protocol version that is.
Vendor
A 32-byte NUL terminated string containing the device's vendor name.
Product
A 32-byte NUL terminated string containing the device's product name.
Revision
A 12-byte NUL terminated string containing the device's revision
number.
Byte Offset
+-----------------------------------------+-----------------------------------------+
0 | Magic Number |
+ +
2 | |
+-----------------------------------------+-----------------------------------------+
4 | Message ID |
+ +
6 | |
+-----------------------------------------+-----------------------------------------+
8 | Protocol Version = 0 | Command = 1 |
+-----------------------------------------+-----------------------------------------+
10 | MAC Address |
+ +
12 | |
+ +
14 | |
+-----------------------------------------+-----------------------------------------+
16 | IP Address |
+ +
18 | |
+-----------------------------------------+-----------------------------------------+
20 | Network Acquisition Mode | Supported Protocol Version |
+-----------------------------------------+-----------------------------------------+
22 | Vendor |
+ +
. . .
. . .
. . .
+ +
52 | |
+-----------------------------------------+-----------------------------------------+
54 | Product |
+ +
. . .
. . .
. . .
+ +
84 | |
+-----------------------------------------+-----------------------------------------+
86 | Revision |
+ +
. . .
. . .
. . .
+ +
96 | |
+-----------------------------------------+-----------------------------------------+
