SwitchableUSB – 3 Supported Messages
12
3.6 Reply Extended Device Information
Sent by a device to a client in response to a Request Extended Device Information message.
3.6.1 Field Descriptions
ENCODER/DECODER
0=Device is a ENCODER, 1=Device is a DECODER
Paired With MAC Address
MAC address of a device that this device is paired with. This field is
optional and may be repeated up to 7 times.
Byte Offset
+-----------------------------------------+-----------------------------------------+
0 | Magic Number |
+ +
2 | |
+-----------------------------------------+-----------------------------------------+
4 | Message ID |
+ +
6 | |
+-----------------------------------------+-----------------------------------------+
8 | Protocol Version = 3 | Command = 1 |
+-----------------------------------------+-----------------------------------------+
10 | ENCODER/DECODER | Paired With MAC Address
|
+--> +-----------------------------------------+ +
| 12 | |
| + +
| 14 | |
| + +-----------------------------------------+
| 16 | |
+--> +-----------------------------------------+
|
+--- Repeated 0 or 1 times for a DECODER or a ENCODER in point-to-point mode or 0 to 7 times for
a ENCODER with virtual hub enabled
