KT-107, KT-107RB - Defining the KT-107, KT-107RB
6
KT-107 Tabletop Mount
This section defines the KT-107 tabletop mount.
Figure 3: Tabletop Mount Front View
#
Feature
Function
Screw Openings (x2)
For attaching the Touch Panel to the tabletop mount using the supplied
M2x4 screws (see Mounting the KT-107 on a Table on page 9).
M5x60 Secure Screw
Opening
For safely securing the tabletop mount to the table from underneath (see
Figure 8).
