Kramer SID-X1N

8 SID-X1N - Connecting the SID-X1N
5 Connecting the SID-X1N
Switch off the power to all devices before connecting them to your
SID-X1N. After connecting your SID-X1N connect the power to other
devices.
Figure 3: Connecting the SID-X1N Step-in Commander
To connect the SID-X1N as illustrated in Figure 3:
1. Connect up to four video sources, (for example, a Blu-ray disc player, a
laptop and two computer graphics sources) to the video input connectors.
