14 SID-X1N - Operating the SID-X1N
7 Operating the SID-X1N
This chapter describes the operating procedures of the SID-X1N and comprises:
• Manually selecting an input (see Section 7.1
)
• Taking control of the switcher input (see Section 7.2)
• Locking the EDID (see Section 7.3)
Powering up the SID-X1N recalls from the non-volatile memory the last settings
that were in force when the device was powered down.
The SID-X1N inputs can be selected remotely via the VP-81SIDN. For details on
how to do so, see the VP-81SIDN User Manual.
7.1 Manually Selecting an Input
Note: When the button is lit it is inactive and pressing the button will not activate
the input.
To manually select an input:
• Press the INPUT SELECT button repeatedly until the required input is active
as indicated by the associated LED.
Note: Only inputs that have an active signal can be selected.
Note: The manual selection overrides any input selection when in last connected
mode and remains in effect until the device is power cycled.
