Kramer SID-X1N - 10 Technical Specifications

SID-X1N - Technical Specifications 19
10 Technical Specifications
INPUTS: Video: 1 HDMI on an HDMI connector
1 DP on a DisplayPort connector
1 DVI-D on a DVI-I connector
1 VGA on a 15-pin HD (F) connector
Audio:
1 Unbalanced stereo audio on a 3.5mm mini jack
OUTPUTS:
1 TP on an RJ-45
1 Unbalanced stereo audio in a 3.5mm mini jack
PORTS: 1 RS-232 3-pin terminal block for programming
CONTROLS: Front panel buttons, remote step-in switch, remote input
selection switches, RS-232
ANALOG AUDIO
INPUT:
Maximum level—3Vpp
REMOTE LED
IMPEDANCE:
5V, 300Ω approx.
STANDARDS: HDMI with x.v.Color™ and 3D
HDCP: Works with sources that support HDCP repeater mode
MAXIMUM DATA
RATE:
4.95Gbps (1.65Gb per graphics channel)
MAXIMUM STEP-IN
DISTANCE:
50m (164ft) up to 1080p @60Hz @24bpp
POWER
CONSUMPTION:
12V DC, 1.1A
COMPLIANCE
STANDARDS:
CE, UL
OPERATING
TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE
TEMPERATURE:
–40° to +70°C (–40° to 158°F)
HUMIDITY: 10% to 90%, RHL non-condensing
COOLING:
Convection, vents
ENCLOSURE TYPE:
Aluminium
DIMENSIONS: 18.8cm x 11.3cm x 2.5cm (7.4” x 4.5” x 1”) W, D, H rack-
mountable
WEIGHT:
0.48kg (1.1lbs) approx.
INCLUDED
ACCESSORIES:
Power adapter
OPTIONS: 19“ Rack adapter RK-T2B, RTBUS-12, RTBUS-22, SID-X1NBP
Kit (substitute black top plate for the SID-X1N to blend in with
the color of the modular TBUS-10xl)
