SID-X2N - Technical Specifications
17
17
10 Technical Specifications
INPUTS:
Video:
1 HDMI on an HDMI connector
1 DP on a DisplayPort connector
1 DVI-D on a DVI-I connector
1 VGA on a 15-pin HD (F) connector
Audio:
1 Unbalanced stereo audio on a 3.5mm mini jack
OUTPUTS:
1 HDBaseT on an RJ-45
1 Unbalanced stereo audio in a 3.5mm mini jack
PORTS:
1 RS-232 3-pin terminal block for programming
CONTROLS:
Front panel buttons, remote step-in switch, remote input selection
switches
STANDARDS:
HDMI with Deep Color, x.v.Color™ and 3D
HDCP: Works with sources that support HDCP repeater mode
MAXIMUM
TRANSMISSION
DISTANCE:
180m (590ft) up to 1080p @60Hz @24bpp in extended mode
130m (430ft) up to 1080p @60 @36bpp in normal mode
POWER
CONSUMPTION:
12V DC, 720mA
OPERATING
TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE
TEMPERATURE:
–40° to +70°C (–40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
18.8cm x 11.3cm x 2.5cm (7.4” x 4.5” x 1”) W, D, H rack-
mountable
WEIGHT:
0.48kg (1.1lbs) approx.
INCLUDED
ACCESSORIES:
Power adapter
OPTIONS:
19“ Rack adapter RK-T2B, RTBUS-12, RTBUS-22, SID-X1BP Kit
(substitute black top plate for the SID-X1N to blend in with the
color of the modular TBUS-10xl)
