SID-X2N - Overview
3 Overview
The SID-X2N accepts an HDMI, DisplayPort, DVI and PC graphics video input, as
well as an unbalanced stereo audio input (which is embedded into the output
signal), and transmits the signal via HDBaseT (Twisted Pair) cable to a compatible
receiver (for example, the TP-580Rxr). The device also provides an unbalanced,
stereo audio output.
The SID-X2N provides:
 A bandwidth of up to 10.2Gbps (3.4Gbps per graphic channel) in normal
mode; up to 4.95Gbps (1.65Gbps per graphic channel) in ultra mode
 A range to a receiver of up to 130m (430ft) in normal mode (1080p@60Hz
@36bpp); up to 180m (590ft) in extended range mode (1080p@60Hz
@24bpp) when using BC−HDKat6a cables
For optimum range and performance, use Kramer's BC−DGKat524,
BC−HDKat6a and BC−DGKat7a23 shielded twisted pair (STP) cables.
Note that the transmission range depends on the signal resolution,
graphics card and display used. The distance using non-Kramer CAT 5,
CAT 6, and CAT 7 cables may not reach these ranges.
In particular the SID-X2N: features:
 HDTV support
 HDMI with Deep Color, x.v.Color™ and 3D
 HDCP compliancy—works with sources that support HDCP repeater mode
 Automatic live input detection based on video clock presence
 Automatic input selection based on manual selection or last connected input
 Automatic analog audio detection and embedding
 I-EDIDPro™ Kramer Intelligent EDID Processing™ – Intelligent EDID
handling & processing algorithm ensures Plug and Play operation for HDMI
systems
 A lockable EDID
 Equalization and reclocking of the data
