7.2 Controlling the Gamma and Color
Figure 20 and Table 6 define the Gamma and Color Screen.
Figure 20: Gamma and Color Screen
Table 6: Gamma and Color Screen Functions
Button Function
Normal Average Setting
Presentation Higher black level
Cinema Higher white balance
Nature Higher green level
User 1
User 2
Set to customize the Gamma (from –10 to 10), Color Temperature (red
green and blue), Color Manager (red, green, blue and yellow). Save
(press MENU) User 1 and User 2 to recall for later use
7.3 Selecting the Source
Figure 21 illustrates the Source screen, displaying the active source
1
(main
screen). Scroll up and down to change the source (same as selecting an
INPUT with the remote transmitter or via the INPUT SELECTOR buttons).
Figure 21: Source Selection Screen
1
Only VP-724xl has 2 VGA inputs; VP-719xl, VP-720xl and VP723xl have 1 VGA input
