8
Operation (continued)
2
Install a Handle on a Drawer (continued)
h. Hold the jig rmly against the face of the drawer and drill the holes using the Adjustable Drill
Guides (E).
i. Install the handle and repeat the process for each drawer.
2h
E
E
Note When adding hardware to a cabinet with multiple drawers of the same width, add the End
Stop (D) for repeatable alignment if the width of the drawer allows.
