After setting your selections, press the previous key once to return to
the
CONFIGURE LEVELS screen.
Use the
PLII CONTROL menu to adjust the signal for Dolby Pro Logic II
music mode, which derives a 5.0 signal from two-channel material.
DIMENSION
You can adjust the sound field toward the front or rear loudspeakers,
to achieve a more suitable balance from all loudspeakers with certain
recordings. The adjustment range is 0 (maximum surround) to 6
(center). The default setting is 3 (neutral).
CENTER WIDTH
You can adjust how much of the center output signal is spread to the
left and right channel outputs. The adjustment range is from 0 (maxi-
mum center channel signal) to 7 (lowest signal; effectively mutes the
center channel).
Select
PLII CONTROL from the CONFIGURE LEVELS menu. The PLII CONTROL
screen appears:
PLII Control
