3 INSTALLATION
24
OPTIMASS 6000
www.krohne.com 02/2016 - 4001894004 - MA OPTIMASS 6000 R04 en
3.4.14 Zero calibration
The procedure for zero calibration is contained in the converter handbook. However, the
following information should be considered when installing the meter.
3.4.15 Sunshades
The meter MUST be protected from strong sunlight.
Zero calibration
1 Where the meter has been installed vertically, install shut-off valves either side of the meter to assist with zero cali-
bration.
2 If the process flow cannot be stopped, install a bypass section for zero calibration.
1 Horizontal installation
2 Vertical installation
MA_OPTIMASS_6000_en_160222_4001894004_R04.book Page 24 Tuesday, February 23, 2016 4:03 PM
