6.5.2 NAMUR dimensions
The following face to face dimensions comply with NAMUR NE132
mm (±3)
S15 S25 S50 S80 S100 S150 S250
PN10
PN10PN10
PN10
DN250 - - - - - - 2100
PN16
PN16PN16
PN16
DN100 - - - - 1000 - -
DN150 - - - - - 1200 -
DN200 - - - - - - 2100
PN40
PN40PN40
PN40
DN 15 510 - - - - - -
DN 25 - 600 - - - - -
DN 50 - - 715 - - - -
DN 80 - - - 915 - - -
inches (±0.12)
S15 S25 S50 S80 S100 S150 S250
PN10
PN10PN10
PN10
DN250 - - - - - - 82.7
PN16
PN16PN16
PN16
DN100 - - - - 39.4 - -
DN150 - - - - - 47.2 -
DN200 - - - - - - 82.7
PN40
PN40PN40
PN40
DN 15 20.1 - - - - - -
DN 25 - 23.6 - - - - -
DN 50 - - 28.1 - - - -
DN 80 - - - 36 - - -
