TECHNICAL DATA 6
31
OPTIMASS 6000
www.krohne.com02/2016 - 4001894004 - MA OPTIMASS 6000 R04 en
Zero stability
Zero stabilityZero stability
Zero stability
08 < 0.03 kg/h
10 < 0.06 kg/h
15 < 0.19 kg/h
25 < 0.95 kg/h
50 < 1.8 kg/h
80 < 3.9 kg/h
100 < 8.8 kg/h
150 < 16 kg/h
200 < 30 kg/h
250 < 50 kg/h
Reference conditions
Reference conditionsReference conditions
Reference conditions
Product Water
Temperature +20°C / +68°F
Operating pressure 1 barg / 14.5 psig
Effect on sensor zero point caused by a shift in process temperature
Effect on sensor zero point caused by a shift in process temperatureEffect on sensor zero point caused by a shift in process temperature
Effect on sensor zero point caused by a shift in process temperature
Standard temperature range
All materials sizes 08...10 0.0010% of nominal flow per 1°C / 0.00056% of nominal flow per 1°F
All materials sizes 15...250 0.00075% of nominal flow per 1°C / 0.00042% of nominal flow per 1°F
High temperature range
All materials sizes 08...250 0.008% of nominal flow per 1°C / 0.0044% of nominal flow per 1°F
Pressure effect on mass flow rate
Pressure effect on mass flow ratePressure effect on mass flow rate
Pressure effect on mass flow rate
All materials sizes 08...50 0.005% per 1 barg / 0.00034 % per 1 psig
All materials sizes 80...100 0.0055% per 1 barg / 0.00038 % per 1 psig
All materials sizes 150...250 0.008% per 1 barg / 0.00055 % per 1 psig
Density
DensityDensity
Density
Measuring range
100...3000 kg/m
3
/ 6...187 lbs/ft
3
Accuracy
±1 kg/m
3
/ ±0.06 lbs/ft
3
On site calibration
±0.2 kg/m
3
/ ±0.012 lbs/ft
3
Process temperature effect 0.015 g/l per 1°C / 0.0083 g/l per 1°F
Temperature
TemperatureTemperature
Temperature
Accuracy ± 0.5°C / ±0.9°F (± 0.5% of reading)
Operating conditions
Nominal flow rates
Nominal flow ratesNominal flow rates
Nominal flow rates (1 barg / 14.5 psig pressure drop)
08 600 kg/h / 22 lbs/min
10 1200 kg/h / 44 lbs/min
15 3800 kg/h / 139 lbs/min
25 19000 kg/h / 698 lbs/min
50 35000 kg/h / 1286 lbs/min
80 78000 kg/h / 2866 lbs/min
100 175000 kg/h / 6430 lbs/min
150 320000 kg/h / 11758 lbs/min
