TECHNICAL DATA 6
37
OPTIMASS 6000
www.krohne.com02/2016 - 4001894004 - MA OPTIMASS 6000 R04 en
6.3 Measuring accuracy
Measuring error
The measuring error is obtained from the combined effects of accuracy and zero stability.
Reference conditions
6.4 Guidelines for maximum operating pressure
Notes:
• Ensure that the meter is used within its operating limits
• All hygienic process connections have a maximum operating rating of 10 barg
at 150°C / 145 psig at 302° F
X nominal flow rate [%]
Y measuring error [%]
Product Water
Temperature +20°C / +68°F
Operating pressure 1 barg / 14.5 psig
MA_OPTIMASS_6000_en_160222_4001894004_R04.book Page 37 Tuesday, February 23, 2016 4:03 PM
