Maximum end loadings (Stainless Steel 316 / 316L)
Maximum end loadings (Hastelloy® and Stainless Steel UNS S31803)
• DN08...50 (axial) loads have been calculated, based on 316L schedule 40 process pipework,
where un-radiographed butt welds have been used in pipe joints.
• DN80...250 (axial) loads have been calculated, based on 316L schedule 80 process pipework,
where un-radiographed butt welds have been used in pipe joints.
• The loads shown are the maximum permitted static load. If loads are cycling (between
tension and compression) these loads should be reduced. For advice, consult the
manufacturer.
-40...55 -50...40 T6 T80
-50...230 T2 T270
-50...400 T1 T440
-40...65 -50...40 T6 T80
-50...230 T2 T270
-50...400 T1 T440
S08 /
S10
S15 S25 S50 S80 S100 S150 S200 S250
Flanges
FlangesFlanges
Flanges
20°C 40 barg 15 kN 25 kN 38 kN 48 kN 99 kN 130 kN 250 kN 300 kN 350 kN
100 barg 12 kN 17 kN 19 kN 15 kN 20 kN 100 kN 120 kN 150 kN 200 kN
230°C 32 barg 7 kN 12 kN 18 kN 25 kN 45 kN 60 kN 50 kN 100 kN 150 kN
60 barg 5 kN 20 kN
400°C 27.4
barg
5 kN 6 kN 10 kN 12 kN 20 kN 50 kN 80 kN 100 kN 150 kN
40 barg 4 kN 5 kN 20 kN
Hygienic (all connections)
Hygienic (all connections)Hygienic (all connections)
Hygienic (all connections)
150°C 10 barg 5 kN 9 kN 12 kN 12 kN 18 kN N/A N/A N/A N/A
H08 / H10 H15 H25 H50 H80 D100 D150 D200
Flanges (not including CRN)
Flanges (not including CRN)Flanges (not including CRN)
Flanges (not including CRN)
20°C 200 barg 12 kN 17 kN 19 kN 15 kN 20 kN 100 kN 120 kN
230°C 145 barg 5 kN 20 kN
Flanges (CRN regions)
Flanges (CRN regions)Flanges (CRN regions)
Flanges (CRN regions)
20°C 200 barg
1
12 kN 17 kN 19 kN 15 kN 20 kN 60 kN 30 kN 10 kN
230°C 145 barg
2
5 kN 20 kN
1 D200 limited to 180 barg at 20°C
2 D100 and D150 limited to 120 barg at 230°C. D200 limited to 110 barg at 230°C
