Notes
• The maximum operating pressure will be either the flange rating or the measuring tube
rating, WHICHEVER IS THE LOWER!
WHICHEVER IS THE LOWER!WHICHEVER IS THE LOWER!
WHICHEVER IS THE LOWER!
• The manufacturer recommends that the seals are replaced at regular intervals. This will
maintain the hygienic integrity of the connection.
6.5 Dimensions and weights
6.5.1 Flanged versions
Meter weights
The weights shown are for meters fitted with PN40 flanges. Smaller or larger flange sizes will
affect the overall weight. For further information, please contact the manufacturer.
kg
S08 S10 S15 S25 S50 S80 S100 S150 S200 S250
Aluminium
(compact)
9.3 10.1 12.9 23.5 29.4 58.9 94.3 193.6 443.6 911.2
Stainless Steel
(compact)
15.2 16 18.8 29.4 35.3 64.8 100.2 199.5 449.5 917.1
Aluminium
(remote)
5.8 6.6 9.4 19.9 25.9 55.4 90.8 190.1 440 907.6
Stainless Steel
(remote)
6.6 7.3 10.2 20.7 26.6 56.1 91.5 191.5 440.8 908.4
Heating jacket add 3.1 4.5 7 7.9 12.7 15.7 27.6 N/A
lbs
S08 S10 S15 S25 S50 S80 S100 S150 S200 S250
Aluminium
(compact)
20.5 22.3 28.4 51.8 64.8 129.8 207.9 426.8 978 2008.8
Stainless Steel
(compact)
33.5 35.3 41.4 64.8 77.8 142.9 220.9 440.7 991 2021.9
Aluminium
(remote)
12.8 14.5 20.7 43.9 57.1 122.1 200.2 419.1 970 2001
Stainless Steel
(remote)
14.55 16.1 22.5 45.6 58.6 123.7 201.7 422.2 971.8 2002.7
Heating jacket add 6.8 9.9 15.4 17.4 28 34.6 60.8 N/A
