KROHNE OPTIMASS 6000 - Burst Disc Option

TECHNICAL DATA 6
59
OPTIMASS 6000
www.krohne.com02/2016 - 4001894004 - MA OPTIMASS 6000 R04 en
6.5.7 Burst disc option
Dimensions
mm
S08 S10 S15 S25 S50 S80 S100 S150 S200 S250
A 76 92 135 57 74 175 160 220
B 38.5 62 0 0 0 0 0 60
inches
S08 S10 S15 S25 S50 S80 S100 S150 S200 S250
A 3.0 3.6 5.3 2.2 2.9 6.9 6.3 8.7
B 1.52 2.4 0 0 0 0 0 2.4
