6 TECHNICAL DATA
54
OPTIMASS 6000
www.krohne.com 02/2016 - 4001894004 - MA OPTIMASS 6000 R04 en
6.5.3 Hygienic versions
Dimension B for meters with Stainless Steel measuring tubes
mm (±5)
S08 S10 S15 S25 S50 S80
Tri-clover
Tri-cloverTri-clover
Tri-clover
½¨ 308 320 - - - -
1¨ - - 477 - - -
1½¨ - - - 563 - -
2¨ - - - - 662 -
3¨ - - - - - 842
Tri-clamp DIN 32676
Tri-clamp DIN 32676Tri-clamp DIN 32676
Tri-clamp DIN 32676
DN15 301 313 - - - -
DN25 - - 477 - - -
DN40 - - - 563 - -
DN50 - - - - 662 -
DN80 - - - - - 855
Tri-clamp ISO 2852
Tri-clamp ISO 2852Tri-clamp ISO 2852
Tri-clamp ISO 2852
1¨ - - 483 - - -
1½¨ - - - 569 - -
2¨ - - - - 668 -
3¨ - - - - - 848
DIN 11864-2 Form A (female)
DIN 11864-2 Form A (female)DIN 11864-2 Form A (female)
DIN 11864-2 Form A (female)
DN15 345 357 - - - -
DN25 - - 514 - - -
DN40 - - - 610 - -
DN50 - - - - 709 -
DN80 - - - - - 915
