TECHNICAL DATA 6

OPTIMASS 6000

www.krohne.com02/2016 - 4001894004 - MA OPTIMASS 6000 R04 en

Male thread DIN 11851

Male thread DIN 11851Male thread DIN 11851

Male thread DIN 11851

DN15 307 319 - - - -

DN25 - - 492 - - -

DN40 - - - 586 - -

DN50 - - - - 689 -

DN80 - - - - - 889

Male thread SMS

Male thread SMSMale thread SMS

Male thread SMS

1¨ - - 464 - - -

1½¨ - - - 566 - -

2¨ - - - - 665 -

3¨ - - - - - 847

inches (±0.2)

S08 S10 S15 S25 S50 S80

Tri-clover

Tri-cloverTri-clover

Tri-clover

½¨ 12.1 12.6 - - - -

1¨ - - 18.8 - - -

1½¨ - - - 22.2 - -

2¨ - - - - 26 -

3¨ - - - - - 33.1

Tri-clamp DIN 32676

Tri-clamp DIN 32676Tri-clamp DIN 32676

Tri-clamp DIN 32676

DN15 11.8 12.3 - - - -

DN25 - - 18.8 - - -

DN40 - - - 22.2 - -

DN50 - - - - 26 -

DN80 - - - - - 33.7

Tri-clamp ISO 2852

Tri-clamp ISO 2852Tri-clamp ISO 2852

Tri-clamp ISO 2852

1¨ - - 19 - - -

1½¨ - - - 22.4 - -

2¨ - - - - 26.3 -

3¨ - - - - - 33.4

DIN 11864-2 Form A (female)

DIN 11864-2 Form A (female)DIN 11864-2 Form A (female)

DIN 11864-2 Form A (female)

DN15 13.6 14 - - - -

DN25 - - 20.2 - - -

DN40 - - - 24 - -

DN50 - - - - 27.9 -

DN80 - - - - - 36

mm (±5)

S08 S10 S15 S25 S50 S80

MA_OPTIMASS_6000_en_160222_4001894004_R04.book Page 55 Tuesday, February 23, 2016 4:03 PM
